Metal P Clip (Rubber Lined) - Max Dia-13mm - Width-20mm

Product image 1
Product image 2
Product image 3
Product image 4

Metal P Clip (Rubber Lined) - Max Dia-13mm - Width-20mm

Description

HCLs Zinc Plated Steel Rubber lined P clips have an elastomer sheathing that absorbs jolts and vibrations, preventing damage to cables and hoses; and also acts as an excellent electrical insulator. The PK series Rubber lined P Clip is manufactured in accordance with DIN3016, incorporating a reinforced fastening hole and is made from Zinc Plated Steel.

Downloads

Product Specifications

  • Max diameter mm - inch13 - 0.51
  • Offset distance mm - inch21.0 - 0.83
  • Hole diameter mm - inch8.4 - 0.33
  • Band Thickness mm - inch1.0 - 0.04
  • Rubber width mm - inch24 - 0.94
  • Manufactured According toDIN3016
  • Hazardous Goods No
  • RoHS Compliant Yes

Features

  • Manufactured to DIN3017 Standard
  • Smooth Underside
  • Bevelled Edges Protect Hose
  • Exclusive Housing Design
$0.46

Original: $1.31

-65%
Metal P Clip (Rubber Lined) - Max Dia-13mm - Width-20mm—

$1.31

$0.46

Product Information

Shipping & Returns

Description

Description

HCLs Zinc Plated Steel Rubber lined P clips have an elastomer sheathing that absorbs jolts and vibrations, preventing damage to cables and hoses; and also acts as an excellent electrical insulator. The PK series Rubber lined P Clip is manufactured in accordance with DIN3016, incorporating a reinforced fastening hole and is made from Zinc Plated Steel.

Downloads

Product Specifications

  • Max diameter mm - inch13 - 0.51
  • Offset distance mm - inch21.0 - 0.83
  • Hole diameter mm - inch8.4 - 0.33
  • Band Thickness mm - inch1.0 - 0.04
  • Rubber width mm - inch24 - 0.94
  • Manufactured According toDIN3016
  • Hazardous Goods No
  • RoHS Compliant Yes

Features

  • Manufactured to DIN3017 Standard
  • Smooth Underside
  • Bevelled Edges Protect Hose
  • Exclusive Housing Design
